The detachable 3 line 6 axle 120ton detachable gooseneck trailer can realize the separation of the gooseneck and the trailer, and realize the contact between the front end of the vehicle and the ground. After the cargo loading is completed, the semi-trailer can be restored to its original transportation state immediately.
The removable gooseneck trailer is a large truck, mainly used to transport heavy and bulky items, such as building materials, mechanical equipment, etc. Compared with the traditional tractor trailer, the split gooseneck semi-trailer has better carrying capacity and stability, can drive on the highway, and is suitable for long-distance transportation.
3 Line 6 Axle 120ton Detachable Gooseneck Trailer for Sale Price in Toamasina Madagascar
3 Line 6 Axle 120ton Detachable Gooseneck Trailer for Sale Price in Toamasina Madagascar
3 Line 6 Axle 120ton Detachable Gooseneck Trailer for Sale Price in Toamasina Madagascar
1. The gooseneck trailer has a lower cargo platform height for transporting heavy cargo.
2. 3 line 6 axle gooseneck trailer adopts high-strength structural steel, which has a tensile and durable structure.
3. The main beam adopts submerged arc welding technology, which improves the bearing capacity and meets the load requirements under harsh road conditions.
4. The high-quality suspension ensures its high load-bearing capacity and increases the ability to resist torsion, impact and impact.
Dimension: 15800mm x 3000mm x 2500mm
Loading capacity(T): 120T
Axle: 13T/16T
Rim: 8.0-20 or 900*22.5
Tire: 8.25R20/10.00R20/11.00R20/12R22.5
Suspension: Mechanical suspension or air suspension
Spring leaf: 120(W)mmx16(Thickness)mmx10 layers
Kingpin: JOST brand 2.0 or 3.5inch(bolted or welded type)
Tare weight: About 9.5-19T
Main beam: Height: 500mm; Width: 230mm; Side beam: 250 I-beam 10/8/10; Material: HG60 high-strength steel.
Bottom Platform: 5mm thick, checkered plate
Hydraulic cylinder: 12KW diesel engine with hydraulic station
ABS: Optional
Valve: WABCO valve
Light: LED light
Voltage: 24V
Tool box: 1 set
If you are interested in this 3 line 6 axle detachable gooseneck trailer, welcome to leave your message!
We will provide more details, quotation, catalog, drawing, videos for you!
